Description
The SFJCL100 Telescopic Jib is an heavy duty 10 tonne general purpose long reach forklift jib designed to suit most lifting and maintenance requirements of larger forklifts.
FEATURES:
• 3.56m reach when fully extended allowing for long reach lifts
• 2.19m overall length when retracted
• Wide pockets suit forklifts with hydraulic tine positioners
• Supplied with safety swivel hook and shackle
• Slip-on attachment and safety chain allows quick connection to a forklift
• Zinc finish
| Working Load Limit (WLL) | 10000kg |
| Load Centre | 920mm |
| Unit Weight | 515kg |
| Fork Pocket Size | 230 x 110mm |
| Fork Pocket Centres | 875mm |
|
Working Load Limit (WLL) per Position |
||||||||
|
Position |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
|
Extension |
920 |
1380 | 1805 | 2045 | 2425 | 2805 | 3185 | 3565 |
|
WLL (kg) |
10000 |
8550 | 7600 | 6600 | 5000 | 2600 | 1520 | 960 |
** Please note, lead time & prices may vary due to raw material fluctuations, Due to item bulk please contact us on (07) 5358 0646 or email us on sales@ncfork.com.au for confirmation**
